The video above shows how to replace blown fuses in the interior fuse box of your 2000 Jeep Cherokee in addition to the fuse panel diagram location. Electrical components such as your map light, radio, heated seats, high beams, power windows all have fuses and if they suddenly stop working, chances are you have a fuse that has blown out. 2000-2001: Oxygen Sensor Downstream Relay, Oxygen Sensor Upstream Relay: 18: 15: 2000-2001: Fuel Injectors, Coil Rail, Coil Capacitor: 19: 20 or 25: 1997-1999: Automatic Shut Down Relay (25A) 2000-2001: Headlamp Switch, Data Link Connector, Power Antenna Relay (20A) 20: 15: Combination Flasher: 21: 15 or 20

The Jeep Cherokee XJ has two fuses boxes. The first one is located under the hood. It is a black box that is located between the battery and the engine coolant tank. The top to the box is removed by pressing in the tabs as you left the top off. Figure 1. Under the hood fuse box location. The second fuse box is located on the interior passenger. The owners manual for the 2000 is missing the fusebox info. But the info is there after wading through all the circuit diagrams. Hi & Lo beam fuses in the junction box. I also have that list you posted but it conflicts with the factory info on pages 8W - 50 - 2 and 8W - 50 - 4. Hi beam is fuses #3 & #16 / Lo beam is fuses #4 & #5 according.
